The Renault Trafic is a Medium Van which is available in two lengths and two heights known as L1/L2 and H1/H2 – and is also offered as a Crew Van too.
The Renault Trafic is one of the most generous vans in its class, with the standard L1 measuring just over five metres at 5080mm. The longer L2 version stretches to 5480mm, comparing well against rivals like the Ford Transit Custom L2 and Citroen Dispatch XL.
The Crew Van is available exclusively in L2 form and comes with a three-wide bench seat for rear passengers, adding extra versatility for carrying both people and cargo.
Inside, the Trafic offers equally impressive space, with 5.8 cubic metres of load volume in the L1/H1 and up to 6.7 cubic metres in the larger L2/H1 model.
The Renault Trafic offers a clever 'trap door' option, where the front passenger seat folds down and a hatch in the bulkhead opens to extend load length to 4150mm. This makes it ideal for carrying longer items like timber or poles.
Unlike many rivals, the Trafic is also available with a taller H2 roof, offered on both L1 and L2 models. While H1 versions stand at 1971mm - low enough for most multi-storey car parks - the H2 raises height to 2495mm.
This added roof height significantly boosts cargo capacity, with up to 6.7 cubic metres in L1/H2 form and an impressive 8.9 cubic metres in the L2/H2.
| RENAULT TRAFIC DIMENSIONS | L1 H1 | L2 H1 | L1 H2 | L2 H2 | Crew Van |
| Exterior Length (mm) | 5080 | 5480 | 5080 | 5480 | 5480 |
| Exterior Height (mm) | 1971 | 1967 | 2495 | 2498 | 1967 |
| Exterior width inc. door mirrors (mm) | 2283 | 2283 | 2283 | 2283 | 2283 |
| Wheelbase (mm) | 3098 | 3498 | 3098 | 3498 | 3498 |
| Maximum Width of Side Sliding Door (mm) | 1030 | 1030 | 1030 | 1030 | 1030 |
| Maximum Width of Rear Opening (mm) | 1391 | 1391 | 1391 | 1391 | 1391 |
| Maximum Load Height of Rear Opening (mm) | 1320 | 1320 | 1820 | 1820 | 1320 |
| Maximum Load Length at Floor (mm) | 2537 | 2937 | 2537 | 2937 | 2423 |
| Maximum Load Height (mm) | 1387 | 1387 | 1898 | 1898 | 1387 |
| Maximum Load Width (mm) | 1662 | 1662 | 1662 | 1662 | 1662 |
| Width Between Wheelarches (mm) | 1268 | 1268 | 1268 | 1268 | 1268 |
| Maximum Load Volume (cu m) | 5.8 | 7.8 | 6.7 | 8.9 | 4.0 |
The Renault Trafic is only available with a diesel engine with the choice of three outputs - 130, 150 and 170 - and offers a generous payload of between 881kg and 1032kg.
All versions of the Renault Trafic offer a brakes towing capacity of 2500kg, making it competitive versus its main Medium Van rivals.
| RENAULT TRAFIC LOADS, TOWING & WEIGHTS | 2.0 Blue dCi 130 Advance L1 H1 | 2.0 Blue dCi 150 Extra L1 H1 | 2.0 Blue dCi 150 Extra Sport L1 H1 | 2.0 Blue dCi 170 Extra Sport L1 H1 | 2.0 Blue dCi 150 L1 H2 | 2.0 Blue dCi 150 L2 H2 |
| Payload Capacity (kg) | 881 | 1013 | 1012 | 987 | 957 | 1032 |
| Gross Vehicle Weight (kg) | 3070 | 3070 | 3070 | 3070 | 3010 | 3010 |
| Kerbweight (kg) | 2039 | 2057 | 2058 | 2083 | 1943 | 1978 |
| Max. Braked Towing Weight (kg) | 2500 | 2500 | 2500 | 2500 | 2500 | 2500 |
| Representative to Rivals | Renault Trafic 2.0 Blue dCi 150 Extra L2 H2 | Maxus Deliver 7 2.0 D L2 H2 | Nissan Primastar 2.0dCi Tekna L2 H2 | Volkswagen Transporter LWB H2 |
| Exterior Length (mm) | 5480 | 5372 | 5480 | 5450 |
| Exterior Height (mm) | 2498 | 2420 | 2486 | 2480 |
| Wheelbase (mm) | 3498 | 3357 | 3498 | 3500 |
| Maximum Width of Side Sliding Door (mm) | 1030 | 990 | 1030 | 1400 |
| Maximum Load Length at Floor (mm) | 2937 | 2913 | 2937 | 3022 |
| Maximum Load Height (mm) | 1898 | 1693 | 1898 | 1870 |
| Maximum Load Width (mm) | 1662 | 1800 | 1662 | 1777 |
| Width Between Wheelarches (mm) | 1268 | 1390 | 1268 | 1392 |
| Maximum Load Volume (cu m) | 8.9 | 9.2 | 8.9 | 9.0 |
| Payload Capacity (kg) | 1032 | 1200 | 1089 | 1230 |
| Gross Vehicle Weight (kg) | 3010 | 3500 | 2900 | 3225 |
| Max. Braked Towing Weight (kg) | 2500 | 2000 | 2500 | 2800 |
