The Peugeot Expert is a Medium Van that is offered in two body sizes – Standard and Long – either as a Panel Van or a Crew Van
The Peugeot Expert measures just under five-metres in Standard (L1) guise at 4981mm, while the Long (L2) version is 5331mm in length. The external dimensions are the same for the Crew Van depending on whether you select Standard or Long body style for this version.
The Peugeot Expert is identical in size to that of its sibling Medium vans - the Citroen Dispatch, FIAT Scudo, Vauxhall Vivaro and Toyota Proace - with no variation in the external dimensions or interior room.
As such, the Expert is competitive with other models in the Medium van class, while it has specially designed features which serve to amplify its practical attributes.
The Peugeot Expert Long (L2) gains its extra length from an extended rear overhang rather than between the wheels, helping reduce wheelarch intrusion at the rear door opening. It comes with three front seats as standard, while the Crew Van version - available in L1 or L2 - adds a rear bench, allowing up to six occupants.
Load space is competitive for the class, offering 5.3 cubic metres in L1 and 6.1 cubic metres in L2. A load-through bulkhead hatch with a foldable front seat further improves practicality, extending the floor length into the passenger footwell.
This feature increases overall cargo volume to 5.8 cubic metres in L1 or 6.6 cubic metres in L2. Meanwhile, the Crew Van provides 3.2 cubic metres of space in L1 form and 4.0 cubic metres in L2 guise.
| PEUGEOT EXPERT DIMENSIONS | Standard | Long | Crew Van S | Crew Van L |
| Exterior Length (mm) | 4981 | 5331 | 4981 | 5331 |
| Exterior Height (mm) | 1904 | 1935 | 1904 | 1935 |
| Exterior width inc. door mirrors (mm) | 2204 | 2204 | 2204 | 2204 |
| Wheelbase (mm) | 3275 | 3275 | 3275 | 3275 |
| Maximum Width of Side Sliding Door (mm) | 935 | 935 | 935 | 935 |
| Maximum Width of Rear Opening (mm) | 1220 | 1220 | 1220 | 1220 |
| Maximum Load Height of Rear Opening (mm) | 1241 | 1241 | 1241 | 1241 |
| Maximum Load Length at Floor (mm) | 2512/3674 | 2862/4024 | 2017 | 2365 |
| Maximum Load Height (mm) | 1397 | 1397 | 1397 | 1397 |
| Maximum Load Width (mm) | 1636 | 1636 | 1636 | 1636 |
| Width Between Wheelarches (mm) | 1258 | 1258 | 1258 | 1258 |
| Maximum Load Volume (cu m) | 5.3/5.8 | 6.1/6.6 | 3.2 | 4.0 |
The Peugeot Expert Standard length has a payload ranging between 1173kg to 1394kg when paired with one of either turbodiesel versions available (1.5-litre or 2.0-litre).
Choose the Long (L2) specification Expert and the payload ranges between 1121-1335kg.
Choose the 75kWh Peugeot E-Expert and the payload ranges from 937kg to 1001kg.
The Peugeot Expert's towing capacity is dependent on the engine or powertrain you select.
In its most powerful 2.0-litre BlueHDi turbodiesel guise, the Expert can tow braked up to 2500kg, while the 1.5-litre BlueHDi turbodiesel manages 2000kg.
Each electric E-Expert in Standard or Long guise is capable of towing up to 1000kg.
| PEUGEOT EXPERT LOADS, TOWING & WEIGHTS | 1.5 BlueHDi 120 Standard | 2.0 BlueHDi 145 Standard | 2.0 BlueHDi 180 Standard | 75kWh Electric Standard | 1.5 BlueHDi 120 Long | 2.0 BlueHDi 145 Long |
| Payload Capacity (kg) | 1173-1182 | 1349-1384 | 1305 | 1001 | 1121-1130 | 1315-1335 |
| Gross Vehicle Weight (kg) | 2830 | 3100 | 3000 | 3011-3021 | 2830 | 3070-3100 |
| Kerbweight (kg) | 1648-1647 | 1716-1751 | 1695 | 2010-2020 | 1700-1709 | 1755-1771 |
| Max. Braked Towing Weight (kg) | 2000 | 2500 | 2500 | 1000 | 2000 | 2500 |
| 75kWh Electric Long | 2.0 BlueHDi 145 Crew Standard | 2.0 BlueHDi 180 Crew Standard | 75kWh Electric Crew Standard | 2.0 BlueHDi 145 Crew Long | 75kWh Electric Crew Long | |
| Payload Capacity (kg) | 1001 | 1242 | 1260 | 940 | 1172 | 937 |
| Gross Vehicle Weight (kg) | 3044-3053 | 3060 | 3030 | 3094 | 3030 | 3100 |
| Kerbweight (kg) | 2043-2052 | 1818 | 1770 | 2154 | 1858 | 2163 |
| Max. Braked Towing Weight (kg) | 1000 | 2500 | 2500 | 1000 | 2500 | 1000 |
| Representative to Rivals | Peugeot Expert 2.0 BlueHDi Sport Crew Van Standard | Ford Transit Custom 2.0 EcoBlue 150PS Sport Double Cab | Renault Trafic 2.0dCi 170 Extra Sport Crew Van | Vauxhall Vivaro 2.0 CDTi 180PS GS Double Cab |
| Exterior Length (mm) | 4981 | 5050 | 5480 | 4981 |
| Exterior Height (mm) | 1904 | 1968 | 1967 | 1904 |
| Wheelbase (mm) | 3275 | 3100 | 3498 | 3275 |
| Maximum Width of Side Sliding Door (mm) | 935 | 1030 | 1030 | 935 |
| Maximum Load Length at Floor (mm) | 2017 | 1604 | 2537 | 2017 |
| Maximum Load Height (mm) | 1397 | 1427 | 1387 | 1397 |
| Maximum Load Width (mm) | 1636 | 1777 | 1662 | 1636 |
| Width Between Wheelarches (mm) | 1258 | 1392 | 1268 | 1258 |
| Maximum Load Volume (cu m) | 3.2 | 3.3 | 4.0 | 3.2 |
| Payload Capacity (kg) | 1260 | 1028 | 1013 | 1242 |
| Gross Vehicle Weight (kg) | 3030 | 3025 | 3070 | 3060 |
| Max. Braked Towing Weight (kg) | 2500 | 2500 | 2500 | 2500 |
