The Renault Kangoo is a small van available in MWB (Medium Wheelbase) and LWB (Long Wheelbase) configurations, plus Crew Van.
Four powertrains are available with the Kangoo being only small van in its class to be available with petrol, diesel and electric options – a 1.3-litre petrol, 1.5-litre turbodiesel (95 and 115) and 44kWh battery.
The MWB (L1) configuration can be specified with any one of the four engine choices, while the LWB is available with a turbodiesel engine or a battery.
The Renault Kangoo measures 4486mm in MWB guise, while the longer LWB is 4910mm in dimension.
Inside, the Renault Kangoo has a load length of 1810mm (MWB) and 2230mm (LWB), while the total cargo volume is 3.3 cubic metres and 4.2 cubic metres respectively, making it one of the most practical small vans in the segment in terms of interior space
The Renault Kangoo in Extra trim also features a dual bench seat to allow three adults to be seated in the front.
| RENAULT KANGOO DIMENSIONS | MWB | LWB | Crew Van |
| Exterior Length (mm) | 4486 | 4910 | 4910 |
| Exterior Height (mm) | 1864 | 1854 | 1854 |
| Exterior width inc. door mirrors (mm) | 2159 | 2159 | 2159 |
| Wheelbase (mm) | 2716 | 3100 | 3100 |
| Maximum Width of Side Sliding Door (mm) | 615 | 830 | 830 |
| Maximum Width of Rear Opening (mm) | 1256 | 1256 | 1256 |
| Maximum Load Height of Rear Opening (mm) | 1115 | 1115 | 1115 |
| Maximum Load Length at Floor (mm) | 1810 | 2230 | 1330 |
| Maximum Load Height (mm) | 1215 | 1215 | 1215 |
| Maximum Load Width (mm) | 1570 | 1570 | 1570 |
| Width Between Wheelarches (mm) | 1248 | 1248 | 1248 |
| Maximum Load Volume (cu m) | 3.3 | 4.2 | 2 |
The Renault Kangoo petrol/diesel offers a generous payload ranging between 836 and 975kg depending on which engine/powertrain and body configuration you choose.
The entry-level 115PS 1.5dCi turbodiesel LWB Panel Van is the most generous with payload, offering 975kg.
The electric 44kWh Kangoo has a 608kg (MWB) and 764kg (LWB) payload.
The Renault Kangoo has an braked towing capacity of 1500kg across the entire range.
| RENAULT KANGOO LOADS & WEIGHTS | 1.3TCe Petrol MWB | 1.5dCi 95 MWB | 1.5dCi 115 MWB | 44kWh Electric MWB | 1.5dCi 95 LWB | 1.5dCi 115 LWB | 44kWh Electric LWB |
| Payload Capacity (kg) | 836 | 836 | 836 | 608 | 975 | 975 | 764 |
| Gross Vehicle Weight (kg) | 2260-2235 | 2260-2235 | 2260-2235 | 2230 | 2550-2560 | 2550-2560 | 2510 |
| Kerbweight (kg) | 1434-1464 | 1434-1464 | 1434-1464 | 1622 | 1578-1588 | 1578-1588 | 1746 |
| Max. Braked Towing Weight (kg) | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 |
| Renault Kangoo 1.5dCi 115 MWB Extra | Ford Transit Connect 2.0 EcoBlue 122 Limited SWB | Vauxhall Combo 1.5TDi 130 Pro STD | Nissan Townstar 1.3TCe Tekna L1 [Petrol] | Citroen Berlingo 1.5HDi 130 M Enterprise | |
| Exterior Length (mm) | 4486 | 4500 | 4403 | 4486 | 4403 |
| Exterior Height (mm) | 1864 | 1856 | 1796 | 1864 | 1796 |
| Wheelbase (mm) | 2716 | 2755 | 2785 | 2716 | 2785 |
| Maximum Width of Side Sliding Door (mm) | 615 | 703 | 675 | 615 | 675 |
| Maximum Load Length at Floor (mm) | 1810 | 1797 | 1817 | 1810 | 1817 |
| Maximum Load Height (mm) | 1215 | 1272 | 1200 | 1215 | 1200 |
| Maximum Load Width (mm) | 1570 | 1628 | 1630 | 1570 | 1630 |
| Width Between Wheelarches (mm) | 1248 | 1230 | 1229 | 1248 | 1229 |
| Maximum Load Volume (cu m) | 3.3 | 3.1 | 3.3 | 3.3 | 3.3 |
| Payload Capacity (kg) | 836 | 722 | 982 | 724 | 984 |
| Gross Vehicle Weight (kg) | 2235 | 2250 | 2400 | 2180 | 2385 |
| Max. Braked Towing Weight (kg) | 1500 | 1500 | 1000 | 1500 | 1000 |
