The Iveco Daily and electric Iveco eDaily are Large Vans offered in a choice of nine body sizes through a series of length and height variations.
The Daily is one of the most practical models in the commercial vehicle sector by being available in four different length configurations - L2, L3, L4 and L5 - as well as three heights - H1, H2 and H3.
The largest model in the Daily range - L5 H3 - makes it one of the biggest in the class, while its gross vehicle weights range from 3.5-tonnes to a mammoth 7.2-tonnes.
By having so many variations on size, the Iveco Daily offers a wide array of load volume options from the smallest L2 H1 measuring 7.3 cubic metres for its cargo bay, going all the way up to 19.6 cubic metres for the L5 H3.
In its longest L5 guise, the Daily extends to 7680mm in length, while the H3 measures 2860mm in height.
In addition to the Panel Van options, the Iveco Daily is offered as a Crew Van, Luton Van, Chassis Cab, Chassis Double Cab, Dropside and Tipper van.
| IVECO DAILY DIMENSIONS | 3.000 L2 H1 | 3.520 L3 H1 | 3.520 L3 H2 | 3.520 L4 H2 | 3.520 L4 H3 | 4.100 L4 H2 | 4.100 L4 H3 | 4.100 L5 H2 | 4.100 L5 H3 |
| Exterior Length (mm) | 5198 | 5720 | 5720 | 6180 | 6180 | 7280 | 7280 | 7680 | 7680 |
| Exterior Height (mm) | 2280 | 2280 | 2660 | 2660 | 2860 | 2660 | 2860 | 2660 | 2860 |
| Exterior width exc. door mirrors (mm) | 2010 | 2010 | 2010 | 2010 | 2010 | 2010 | 2010 | 2010 | 2010 |
| Wheelbase (mm) | 3000 | 3520 | 3520 | 3520 | 3520 | 4100 | 4100 | 4100 | 4100 |
| Maximum Width of Side Sliding Door (mm) | 1100 | 1200 | 1200 | 1200 | 1200 | 1200 | 1200 | 1200 | 1200 |
| Maximum Width of Rear Opening (mm) | 1530 | 1530 | 1530 | 1530 | 1530 | 1530 | 1530 | 1530 | 1530 |
| Maximum Load Height of Rear Opening (mm) | 1450 | 1450 | 1800 | 1800 | 2000 | 1800 | 2000 | 1800 | 2000 |
| Maximum Load Length at Floor (mm) | 2610 | 3130 | 3130 | 3540 | 3540 | 4680 | 4680 | 5125 | 5125 |
| Maximum Load Height (mm) | 1545 | 1545 | 1900 | 1900 | 2100 | 1900 | 2100 | 1900 | 2100 |
| Maximum Load Width (mm) | 1800 | 1800 | 1800 | 1800 | 1800 | 1800 | 1800 | 1800 | 1800 |
| Width Between Wheelarches (mm) | 1317 | 1317 | 1317 | 1317 | 1317 | 1317 | 1317 | 1317 | 1317 |
| Maximum Load Volume (cu m) | 7.3 | 9.0 | 10.8 | 12.0 | 13.4 | 16.0 | 18.0 | 17.5 | 19.6 |
